Teseek QHY5III485C IMX485 CMOS 4K 3864x2180 Astronomical Planetary Camera 128MB DDR with 1.25-inch Interface
픽업 사용 가능 여부를 로드할 수 없습니다.
Specifications
Brand
Product type
Technical specs
Design and durability
Teseek QHY5III485C IMX485 CMOS 4K 3864x2180 Astronomical Planetary Camera 128MB DDR with 1.25-inch Interface
Specification:
- Model: QHY5III485C
- Image sensor: for Sony IMX485 CMOS
- Mono/Color: color only
- FSI/BSI: BSI
- Sensor size: 1/1.2inch
- Pixel size: 2.9μm x 2.9μm
- Effective pixel area: 3864 x 2180
- Effective pixels: 8.4 Megapixels
- Full well capacity: 12ke-
- Read noise: 0.77e- to 2.4e-
- A/D: 12bit (output as 16bit and 8bit)
- Built-in image buffer: 128MB DDR II memory
- Full frame rates: 44FPS at 8bit
- ROI frame rates: 78.5FPS at 1200lines, 87FPS at 1080lines, 91.5FPS at 1024lines, 97.5FPS at 960lines, 121FPS at 768lines, 190FPS at 480lines
- Exposure time range: 11μs-900sec
- Shutter type: electronic rolling shutter
- Computer interface: USB3.0 Type-B
- Guide port: custom ST-4
- Telescope interface: 1.25-inch, with CS and C-Mount
- Optical window: IR-Cut Filter
- Back focal length: 12mm
- Weight: 90g
Package Included:
- 1 x Planetary Camera
- 1 x Guiding Cable
- 1 x USB3.0 Cable (2m)
- 1 x CS to C Mount Adapter
- 1 x 2.5mm f/1.2 CS Lens
- 1 x 1.25-inch Extension Tube
- 2 x 0.25mm Focusing Adapters
- 1 x Thumb Screw
- 1 x User Manual
